Storage tank integrated into the solar collector, the tank maintains hot water temperatures even if the sun isn’t shining. The pipes in the tank have a 38-gallon capacity rating, enough to satisfy the needs of the homeRead More
Water is heated and stored directly in the solar collector, making hot water available as soon as it’s heated by the sun
Accommodate any roof style with a unit that’s easy to set up
Water is efficiently heated in the integrated storage tank the moment sunlight hits the solar glass
Aluminum profiles and rigid foam insulation at the sides and rear of the solar collector provide total durability
Resilient internal coating offers maximum corrosion resistance and trouble-free performance
Totally transparent insulation delivers maximum heat retention
General Specs | |
| Manufacturer Warranty | 10 Year |
| Capacity (gal.) | 38 |
| Color Finish Name | Gray |
| ADA Compliant | No |
| Smart Compatible | No |
| Wifi Capable | No |
| Collection | GeoSpring™ |
| Product Weight (lbs.) | 115 |
Features | |
| Configuration | ICS |
| Product Type | Solar |
| Cold/hot water connections (inches) | 3/4 MNPT |
| Collector Inclination Angle from horizontal (degrees) | 10 to 75 |
| Gross area (ft) | 19 |
| Heat transfer medium | Water |
| Max. operating pressure (psi) | 60 |
| Net Collector Area (ft²) | 17 |
| Thermal insulation - storage tank (inches) | 1.2 |
| Volume hot water storage tank (gal) | 38 |
Weight and Dimensions | |
| Collector outer dimensions (inches) | 86x33x8 |
| Max height, mount 45/30 (inches) | 28/22 |
| Weight (with mount, no water) (lb) | 125 |
| Weight (with mount, with water) (lb) | 444 |
